Features
Cermet Tipped blades offer several advantages over traditional steel blades. Firstly, they are designed to maintain their cutting edge and overall sharpness for much longer than traditional blades, meaning fewer blade replacements and reduced downtime. Additionally, because the Cermet Tipped material is so hard and durable, these blades can be sharpened and reused multiple times, further extending their lifespan and value.
Cermet Tipped circular Saw Blades for metal cutting is their increased efficiency and precision. The high-speed cutting power of these blades ensures that your cuts are made quickly and cleanly, without the need for any additional finishing work.
Cermet tipped saw blades metal cutting are all produced by laser processing to ensure the accuracy of the substrate size, and the welding of the blade heads is uniformly carried out by fully automated machines to ensure the strength and accuracy of the welding. The precision of the grinding process for the side and tip of the blade is strictly controlled within the qualified range. The final product is completed according to customer requirements and meets the company's quality management requirements. All data must be inspected and qualified before it can be considered a finished product.
parameter
|
Series |
Specification |
Outer Diameter(Ømm) |
Thickness of tip |
Thickness of blade body |
Bore |
Number of teeth |
Teeth |
|
GARO |
165*2.0*1.6*15.88*48T |
165 |
2.0 |
1.6 |
15.88 |
48 |
BT |
|
184*2.0*1.6*15.88*48T |
184 |
2.0 |
1.6 |
15.88 |
48 |
BT |
|
|
203*2.1*1.7*15.88*42T |
203 |
2.1 |
1.7 |
15.88 |
42 |
BT |
|
|
230*2.1*1.7*25.4*46T |
230 |
2.1 |
1.7 |
25.4 |
46 |
BT |
|
|
254*2.4*2.0*25.4*52T |
254 |
2.4 |
2.0 |
25.4 |
52 |
BT |
|
|
305*2.4*2.0*25.4*60T |
305 |
2.4 |
2.0 |
25.4 |
60 |
BT |
|
|
356*2.6*2.2*25.4*72T |
356 |
2.6 |
2.2 |
25.4 |
72 |
BT |
DETAILS
Cermet tipped metal saw blade
The blades are typically made with a high-speed steel body, which can withstand the high heat and pressure generated by the cutting process, and a cermet tipped edge, which is bonded with the body using a brazing process, further enhancing the blade's overall strength and durability.
Fine process to ensure quality
Simple processes such as laser welding are outsourced for processing, while fine processes such as grinding of cutting heads are completed by our company to ensure their quality.
Introduction to Uses
Usage: Precision cutting of angle steel, spiral steelpipe, round pipe, square pipe, steel pipe liner, metalliner, plate, cable pipe and other materials.
Application
Saw Blade Selection
Enhanced Precision
Cermet tipped circular saw blades can make cleaner and more precise cuts, which is particularly beneficial for metal sheets with a thickness of up to 0.5 inches, as compared to other saw blade types.
01
Reduced Heat Buildup
Cermet tipped circular saw blades have a low coefficient of friction, which reduces heat build-up during the cutting process, thereby prolonging the life of the blade.
02
Versatility
Cermet tipped circular saw blades can cut different types of metals, including stainless steel, hardened steel, cast iron, and non-ferrous metals.
03
High Cutting Speed
Cermet tipped circular saw blades are designed for higher RPMs, allowing for faster cuts with higher feed rates, making them ideal for fast-paced industrial applications.
04
