Zhejiang Zhongcun Precision Cutter Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of 900mm saw blade for aluminum in China, featured by quality products and good service. Welcome to wholesale CE approved 900mm saw blade for aluminum from our factory. Contact us for customized service and OEM service.
Features
- Superior Thermal Stability for High-Load Operations: Engineered specifically for massive industrial processing, this Heavy Duty 900mm saw blade for aluminum features advanced heat-treatment and precision stress-relief expansion slots. It maintains exceptional flatness and eliminates thermal deformation even during continuous, high-intensity slicing of Industrial Casting and thick aluminum alloys.
- Premium Custom Carbide for Extended Lifespan: Equipped with Nakamura's exclusive micro-grain, high-density carbide tips. This specialized formula is optimized for Large Diameter Aluminum billets, providing unparalleled wear resistance and minimizing edge chipping under extreme cutting forces.
- Vibration Damping & Noise Reduction: Laser-cut silent slots are strategically integrated to absorb harmonics and suppress resonance, ensuring ultra-smooth feeding, a clean surface finish, and a safer workshop environment.
parameter
|
Specification |
Outer Diameter (Ømm) |
Thickness of tip (mm) |
Bore (Ømm) |
The number of teeth(P) |
Teeth |
Material |
|
850*7.0*50*40 |
850 |
7 |
50 |
40 |
BT |
75Cr1 |
|
900*7.0*5.5*100*180 |
900 |
7 |
100 |
180 |
BC |
|
|
900*8.0*6.0*80*120T |
900 |
8 |
80 |
120 |
BT |
|
|
920*7.5*6.5*65*84T |
920 |
7.5 |
65 |
84 |
||
|
1000*7.5*70*144 |
1000 |
7.5 |
70 |
144 |
DETAILS
Engineered for Harsh Foundry Environments
The specialized BT/BC tooth geometry is fine-tuned to conquer the extreme friction and heat generated in casting yards and heavy extrusion mills. 900mm saw blade for aluminum delivers high-efficiency cutting with minimal material waste and zero tearing.
Heavy-Duty Structural Rigidity
Built upon a reinforced 75Cr1 steel plate, the structural design prevents dynamic deflection and side-wobble during deep cuts. The optimized cutting angle drastically reduces kickback risks when processing giant metal blocks.
Target Slicing Scenarios
Specially designed for aluminum smelting plants, heavy machinery manufacturing, and maritime/aerospace aluminum processing. 900mm saw blade for aluminum is the ultimate tool for cutting oversized aluminum ingots, foundry risers, thick plates, and large-diameter non-ferrous metal bars.
Application
Technical Craftsmanship & QC
1. Dynamic Balancing Test
- Precision Calibration: Every 900mm saw blade undergoes rigorous dynamic balance testing before leaving the factory, keeping the dynamic radial runout strictly within ≤ 0.05mm.
- Vibration-Free Cutting: Completely eliminates uneven centrifugal forces and high-frequency vibrations at high rotational speeds, stabilizing the cutting path, protecting the machine spindle, and extending tooth lifespan.
2. Heat Treatment & Stress Relief Process
- Specialized Core Treatment: The premium 75R1 steel plate undergoes a unique multi-stage heat treatment and localized stress-relief process to ensure exceptional structural rigidity.
- Excellent Thermal Flatness: Even under extreme frictional heat generated by continuous cutting of high-temperature aluminum, the blade retains perfect flatness without warping, bending, or cracking.
3. Resharpening Lifetime
- Extended Tool Longevity: Benefiting from ultra-thick, high-density premium carbide tips, this blade offers outstanding wear resistance and superior re-tipping potential.
- High Cost-Effectiveness: Under normal operating conditions, the blade can be precision-resharpened 5 to 8 times. Each service fully restores factory-level cutting accuracy, drastically reducing the total tooling expenditure for manufacturing plants.
