Zhejiang Zhongcun Precision Cutter Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of 3 inch wood saw blade in China, featured by quality products and good service. Welcome to wholesale CE approved 3 inch wood saw blade from our factory. Contact us for customized service and OEM service.
Features
The Shin-sho Micro-Cut series is not built only for faster cutting. Its main purpose is to keep a small-diameter blade stable when working on high-value wood. For exotic wood, fine instrument wood, and precision joinery, the quality of the cut edge often decides how much trimming, sanding, or rework is needed afterward.
The BA5 tooth geometry and refined tip arrangement allow the blade to enter the material more smoothly, reducing pulling during the cut. On veneered boards, hardwood, fine molding, and instrument components, this tooth design helps create a cleaner smooth edge and lowers the impact of chipping or burrs on the finished part.
In fine woodworking, the real cost is not only the cutting process itself, but also the finishing work after cutting. With its ultra-thin kerf and stable tooth geometry, Shin-sho Micro-Cut helps reduce edge roughness and can cut later sanding cost by around 30% under suitable material and machine conditions. This matters especially for exotic wood and fine instrument wood, where material value is high and rework is costly.
The value of an ultra-thin blade lies in a lighter, narrower, and more controlled cut. A narrower kerf means less material loss, while lower cutting resistance helps the tool run more steadily. For small wooden parts, joinery components, and premium custom woodwork, the ultra-thin kerf helps preserve more usable material and produces a finer cutting edge.
parameter
The specifications below cover different diameters, tooth counts, and kerf thicknesses in the Shin-sho series. Selection should not be based on size alone. Material hardness, machine type, target edge quality, and sanding requirements should also be considered.
|
Series |
Specification |
Outer Diameter(Ømm) |
Thickness of tip |
Thickness of blade body |
Bore |
Number of Teeth |
Teeth |
|
Shin Sho Series
|
100*1.1*0.7*20*30T |
100 |
1.1 |
0.7 |
20 |
30 |
BA5 |
|
125*1.1*0.7*20*40T |
125 |
1.1 |
0.7 |
40 |
|||
|
147*1.4*0.8*20*40T |
147 |
1.4 |
0.8 |
40 |
|||
|
147*1.4*0.8*20*60T |
147 |
1.4 |
0.8 |
60 |
|||
|
165*1.6*1.0*20*50T |
165 |
1.6 |
1.0 |
50 |
|||
|
165*1.6*1.0*20*40T |
165 |
1.6 |
1.0 |
40 |
DETAILS
Ultra-Thin Kerf Design for Power Tools
This 3 Inch wood saw blade is suitable for compact power tools and fine cutting stations. Its ultra-thin kerf lowers cutting resistance and helps the tool run with less load during repeated cuts. For applications that require kerf control and lower material waste, such as instrument wood, fine molding, and small joinery parts, it is easier to achieve a stable edge than with a standard thick-kerf blade.
Designed for Precision Joinery and Fine Instrument Wood
Shin-sho Micro-Cut is better suited for materials where edge quality is important, including exotic wood, hardwood, veneered plywood, MDF, OSB, bamboo, and fine instrument wood. 3 Inch wood saw blade can be used for precision joinery, fine decorative parts, sample making, and premium custom wood components. The key question it answers is not simply whether the blade can cut, but whether the edge remains clean enough after cutting.
Application
This blade is suitable for exotic wood cutting, fine instrument wood processing, precision joinery, decorative veneer trimming, fine molding, and small-batch premium wood parts.
If the user cares more about reducing chipping, lowering sanding work, and improving material utilization than simply cutting as fast as possible, Shin-sho Micro-Cut is a better fit.
About Factory
FAQ
Q: How is this blade different from a regular 3 inch wood saw blade?
A: A regular 3 inch wood saw blade is usually made for general cutting. Shin-sho Micro-Cut focuses more on ultra-thin kerf, edge flatness, and reduced finishing work, making it better for exotic wood, fine instrument wood, and precision joinery.
Q: Can it be used for fine instrument wood?
A: Yes. Fine instrument wood usually requires a clean edge, low material loss, and less finishing work. The ultra-thin kerf and BA5 tooth geometry make this blade suitable for this type of fine cutting.
Q: What is the advantage of an ultra-thin kerf?
A: An ultra-thin kerf lowers cutting resistance, reduces material waste, and helps produce a smoother edge, making it suitable for high-value wood processing.
Q: Can the specification be customized?
A: Yes. Specifications can be discussed based on the target material, machine type, cutting result, and order quantity.
